Specs at a glance
-
Accuracy
class 2 acc. to IEC 60584
ASTM E230 and ANSI MC 96.1 -
Response time
t50 = 3 s
t90 = 9 s -
Max. process pressure (static)
at 20 °C: 90 bar (1305 psi)
-
Operating temperature range
Type K:
max. 920 °C
(max. 1.688 °F)
Type J:
max. 440 °C
(max. 824 °F)
Type N:
max. 920 °C
(max. 1.688 °F)
Type E:
max. 510 °C
(max. 950 °F) -
Max. immersion length on request
up to 13.000,00 mm (511,81'')
Field of application
Specially designed for applications where small size of the probe and light weight are crucial. The TMS21 can be highly customized due to its versatility. It can monitor the temperature on a very high number of points along a line just by using one process connection. It is composed of several low diameters thermocouples protected by one overall primary tube thermowell. Two different product configurations are available, with or without flexible upper thermowell-hose (for axial centering).
Light Chemical processes
Benefits
-
High number of measuring points in a small diameter
-
Low invasiveness temperature profiling probe
-
Easy mounting and cabling
